Meet Butterfly

When butterflies are present,
we know the air is healthy.

Indoor air quality monitoring
Inspired by nature

Explore our devices

Morpho

Our original indoor air quality monitor is designed and engineered to meet WELL V2 standards. ‘Understand at a glance’ colour changing wings indicate when air quality changes. Connect several Morpho monitors to a Chrysalis hub to make your data accessible online.

Measurements

CO2
VOC
PM2.5 & PM10
CH2O (Formaldehyde)
Temp
Humidity

Technologies

Patented LaminAir flow for fast and accurate readings, ensuring fresh air is used for each measurement.

LED wing array for quick at-a-glance air quality feedback.

Certifications

Designed for WELL V2 certification

Connectivity

Bluetooth Low Energy / WiFi (to Chrysalis only)

Power

Cable and wall power adapter included

Maintanance

Annual sensor recalibration with swappable sensor units

Dimension

230 x 288 x 42.5 mm

Mini

Our smaller Butterfly device Mini is designed to measure CO2, Temperature and Humidity. Therefore it is suitable for non WELL certified spaces such as residential and education. Connect Mini to your smartphone for local monitoring, or connect to a Chrysalis hub to manage multiple devices from one online portal.

Features

CO2
Temp
Humidity

Technologies

LED wing array for quick at-a-glance air quality feedback, (triggered by a wave of the hand)

Connectivity

Bluetooth Low Energy / WiFi (to Chrysalis / mobile app)

Power

2x AA batteries, Battery life up to 18 months

Maintanance

Annual sensor recalibration of whole unit

Dimensions

170 x 129 x 33 mm

Antenna

With similar high quality monitoring to Morpho, Antenna provides a battery powered alternative with a more discrete look. Connect several Antenna to a Chrysalis hub to make your data accessible online.

Measurements

CO2
VOC
PM2.5 & PM10
Temp
Humidity

Technologies

Vivid LED ring array for quick at-a-glance air quality feedback (triggered by hand gesture)

Certifications

Designed for WELL V2 certification

Connectivity

Bluetooth Low Energy / WiFi (to Chrysalis only)

Power

5x 18650 batteries, Battery life up to 18 months

Maintanance

Annual sensor recalibration of whole unit

Dimensions

140 x 147 x 42 mm

Chrysalis

Our System hub which acts as a gateway for all of our monitors and provides an independent data channel for secure data transfer to our bespoke client dashboard.

Features

Gateway hub for the Morpho, Mini and Antenna

Technologies

Vivid LED ring array for connectivity options

Connectivity

WiFi, Ethernet, 4G LTE, LoRaWAN for online sync

Power

Cable and wall power adapter included
Power-Over-Ethernet (LAN cable not provided)

Dimensions

103 x 108 x 158 mm

Air Safe

LaminAIR™ flow technology ensures Butterfly devices consistently update all key IAQ measurements to meet the latest international WELL V2 standards for air safety including:

CO2 - Can make rooms stuffy and uncomfortable, reduce cognitive ability and even cause headaches.

‍Humidity - Encourages mold, allergies, and dust mites. If humidity is too low, problems such as dry skin, and a sore throat can arise. Maintaining relative humidity can potentially suppress the transmission of viruses like COVID-19

‍Temperature -  Comfortable room temperatures range from 20-25 C. At night, a cooler room between 15-19 C can help our sleep.

‍VOC - High levels of VOCs can cause nose and throat irritation, headaches, and skin allergies.

‍PM 2.5 - Small enough to stay airborne for long periods of time, when inhaled they can reach all the way into the bloodstream.

‍PM 10 - Larger particles that can cause irritation and damage to the respiratory system.

Formaldehyde - Can cause symptoms ranging from nose and throat irritation to difficulty breathing.

Real Time Data

Butterfly devices operate in real time which means that measurements are communicated instantly to our server and presented immediately to you online. We are very aware of data security and our portal features protected access via individual client login.

Built Different

All Butterfly devices are designed at Imperial College London and built in the UK to exacting standards of quality with an emphasis on sustainability. We think carefully about maintenance, service and ongoing durability to ensure everything we make is future proof. We believe that buying a Butterfly device is an investment which will deliver valuable benefits to our customers for many years.

Understand at a glance

As in nature, we believe that colour is one of the best ways to communicate key information at a glance. We have designed our Butterfly wings to glow in evocative colours which change to indicate IAQ at any time. You can therefore see immediately if there are changes happening that need your attention and conveniently investigate the specifics of those changes via your client login.

A Butterfly for every setting

Visualising IAQ

As our client, you will be provided with a 3D digital model of your space using our Building Information Modelling Technology (BIM). This technique makes it easy to understand the specific IAQ facts and figures in your space so you can quickly see what is happening and make decisions accordingly which could range from opening a window to altering your Building Management System (BMS).

This feature is coming soon. Watch our platform experience demo below.

demo

WELL Accreditation

The Butterfly system is designed to meet the BRE Group certification – the internationally renowned building standards authority which is used by the UK Government. This standard meets and exceeds the requirements for the latest WELL accreditation which means that you can reassure your people that they are occupying a space where their health & wellbeing has been given top priority.
